AD8351 Series

Catalog

LOW DISTORTION DIFFERENTIAL RF/IF AMPLIFIER

Part	Mounting Type	RF Type	Current - Supply (Max)	Current - Supply (Min)	P1dB	Gain	Frequency (Min)	Frequency (Max)	Package Name	Test Frequency	Package Length	Package Width	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Frequency	Package / Case	Current - Supply
Analog Devices Inc./Maxim Integrated AD8351ARM	Surface Mount	General Purpose	32 mA	28 mA	13.5 dBm	26 dB	0 Hz	2.2 GHz	10-MSOP 10-TFSOP	10 MHz	0.118 in	3 mm	5.5 V	3 V
Analog Devices Inc./Maxim Integrated AD8351ARMZ	Surface Mount	General Purpose	32 mA	28 mA	13.5 dBm	26 dB	0 Hz	2.2 GHz	10-MSOP 10-TFSOP	10 MHz	0.118 in	3 mm	5.5 V	3 V
Analog Devices Inc./Maxim Integrated AD8351SCPZ-EP-R7	Surface Mount					1 dB			16-LFCSP-WQ	2.2 GHz	3 mm	3 mm	5.5 V	3 V	2.2 GHz	16-WFQFN Exposed Pad CSP	28 mA
Analog Devices Inc./Maxim Integrated AD8351ARM-REEL7	Surface Mount	General Purpose	32 mA	28 mA	13.5 dBm	26 dB	0 Hz	2.2 GHz	10-MSOP 10-TFSOP	10 MHz	0.118 in	3 mm	5.5 V	3 V
Analog Devices Inc./Maxim Integrated AD8351ARMZ-REEL7	Surface Mount	General Purpose	32 mA	28 mA	13.5 dBm	26 dB	0 Hz	2.2 GHz	10-MSOP 10-TFSOP	10 MHz	0.118 in	3 mm	5.5 V	3 V
