KD20 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; PLUG; FEMALE; 5.5A; 300V

Part	Number of Positions	Color	Features	Plug Wire Entry Angle	Positions Per Level	Number of Levels	Termination Style	Type	Contact Mating Finish	Operating Temperature (Min)	Operating Temperature (Max)	Current - UL	Pitch	Voltage - UL	Mounting Type	Wire Gauge or Range - AWG (Max)	Wire Gauge or Range - AWG (Min)	Contact Material	Insulation Height	Material Flammability Rating	Wire Strip Length (Min)	Wire Strip Length (Max)	Housing Material
McGill Microwave Systems KD2030510000G	20	Green	Mating Flange	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	5.5 A	0.15 in	300 V	Free Hanging (In-Line)	24 AWG	16 AWG	Phosphor Bronze	0.307 in	UL94 V-0	9 mm	10 mm	Thermoplastic
McGill Microwave Systems KD2010520000G	20	Green	Latch Lock	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	5.5 A	0.138 in	160 V	Free Hanging (In-Line)	24 AWG	16 AWG	Phosphor Bronze	0.307 in	UL94 V-0	9 mm	10 mm	Thermoplastic
McGill Microwave Systems KD2030520000G	20	Green	Latch Lock	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	5.5 A	0.15 in	300 V	Free Hanging (In-Line)	24 AWG	16 AWG	Phosphor Bronze	0.307 in	UL94 V-0	9 mm	10 mm	Thermoplastic
McGill Microwave Systems KD2050520000G	20	Green	Latch Lock	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	12 A	5.08 mm	300 V	Free Hanging (In-Line)	24 AWG	14 AWG	Phosphor Bronze	0.429 in	UL94 V-0	11 mm	12 mm	Thermoplastic
McGill Microwave Systems KD2070520000G	20	Green	Latch Lock Retention Latches (Wire Side)	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	12 A	0.197 in	300 V	Free Hanging (In-Line)	24 AWG	14 AWG	Phosphor Bronze	0.429 in	UL94 V-0	11 mm	12 mm	Thermoplastic
McGill Microwave Systems KD2070500000G	20	Green	Retention Latches (Non-Wire Side)	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	12 A	0.197 in	300 V	Free Hanging (In-Line)	24 AWG	14 AWG	Phosphor Bronze	0.429 in	UL94 V-0	11 mm	12 mm	Thermoplastic
McGill Microwave Systems KD2070510000G	20	Green	Mating Flange Retention Latches (Wire Side)	180 °	20	1	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	12 A	0.197 in	300 V	Free Hanging (In-Line)	24 AWG	14 AWG	Phosphor Bronze	0.429 in	UL94 V-0	11 mm	12 mm	Thermoplastic
McGill Microwave Systems KD201051A000G	20	Green		180 °	10	2	Push-In Spring Screwless - Leg Spring	Female Sockets Plug	Tin	-40 °C	115 °C	5.5 A	0.138 in	160 V	Free Hanging (In-Line)	24 AWG	16 AWG	Phosphor Bronze	0.634 in	UL94 V-0	9 mm	10 mm	Thermoplastic
