ADL5380 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
400 MHZTO 6000 MHZQUADRATURE DEMODULATOR
| Part | P1dB | Package / Case | Package Width | Package Name | Package Length | Function | Current - Supply | LO Frequency (Min) | LO Frequency (Max) | Gain | Mounting Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | RF Frequency (Max) | RF Frequency (Min) | Noise Figure | For Use With/Related Products | Supplied Contents | Type | Utilized IC / Part | Contents | Frequency (Min) | Frequency (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 11.6 dBm | 24-WFQFN Exposed Pad CSP | 4 mm | 24-LFCSP | 4 mm | Demodulator | 245 mA | 6 GHz | 400 MHz | 6.9 dB | Surface Mount | 5.25 V | 4.75 V | 6 GHz | 400 MHz | 10.9 dB | |||||||
 Analog Devices Inc./Maxim Integrated | ADL5380 | Board(s) | Demodulator | ADL5380 | Board | 400 MHz | 6 GHz |
