AD9164 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

DIGITAL TO ANALOG CONVERTERS - DAC 16 BIT,6GSPS RF DAC &DDS W/INTERPOLATION

Part	Differential Output	Mounting Type	Output Type	Operating Temperature (Min)	Operating Temperature (Max)	Number of Bits	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Max)	Package Name	Package Width	Package Length	Reference Type	Architecture	Number of D/A Converters	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	DNL (LSB) Tolerance	INL (LSB) Tolerance	Package / Case	Data Interface	Utilized IC / Part	Contents	DAC Type	Number of DAC's	Sampling Rate (Per Second)
Analog Devices Inc./Maxim Integrated AD9164BBCZ	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	165-CSPBGA	8 mm	8 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	165-VFBGA CSPBGA	JESD204B
Analog Devices Inc./Maxim Integrated AD9164BBCARL	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	169-CSPBGA	11 mm	11 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	169-VFBGA CSPBGA	JESD204B
Analog Devices Inc./Maxim Integrated AD9164BBCAZRL	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	169-CSPBGA	11 mm	11 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	169-VFBGA CSPBGA	JESD204B
Analog Devices Inc./Maxim Integrated AD9164BBCA	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	169-CSPBGA	11 mm	11 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	169-VFBGA CSPBGA	JESD204B
Analog Devices Inc./Maxim Integrated AD9164-FMCC-EBZ						16 bits																JESD204B Serial	AD9164	Board	Current	1	12 GHz
Analog Devices Inc./Maxim Integrated AD9164BBCZRL	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	165-CSPBGA	8 mm	8 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	165-VFBGA CSPBGA	JESD204B
Analog Devices Inc./Maxim Integrated AD9164BBCAZ	No	Surface Mount	Current - Unbuffered	-40 °C	85 °C	16 bits	1.14 V	2.375 V	2.625 V	1.326 V	169-CSPBGA	11 mm	11 mm	External Internal	Quad-Switch	1 count	1.326 V	1.14 V	1.7 LSB	2.7 LSB	169-VFBGA CSPBGA	JESD204B
