ADGS1412 Series

Catalog

EVAL BOARD FOR ADGS1412

Part	Supplied Contents	Contents	Function	Primary Attributes	Secondary Attributes	Type	Utilized IC / Part	Charge Injection	Channel-to-Channel Matching (ΔRon)	Package Width	Package Name	Package Length	Current - Leakage (Max)	Switch Circuit Type	Switch Contact	Package / Case	Crosstalk	On-State Resistance (Max)	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Switch Time Toff (Max)	Switch Time Ton (Max)	Number of Circuits	Channel Capacitance (CD(off))	Channel Capacitance (CS(off))	Demultiplexer Outputs	Multiplexer Inputs	Voltage - Supply, Dual (Minimum)	Voltage - Supply, Dual (Nominal)	Voltage - Supply, Dual (Maximum)	-3db Bandwidth	Voltage - Supply, Single (V+) (Minimum)	Voltage - Supply, Single (V+) (Maximum)
Analog Devices Inc./Maxim Integrated EVAL-ADGS1412SDZ	Board(s)	Board	Analog Switch	SPST	SPI Interface(s)	Interface	ADGS1412
Analog Devices Inc./Maxim Integrated ADGS1412BCPZ								-20 pC	100 mOhm	4 mm	24-LFCSP	4 mm	550 pA	SPST	NO	24-VFQFN Exposed Pad CSP	-100 dB	1.8 Ohms	Surface Mount	125 °C	-40 °C	190 ns	135 ns	4	23 pF	22 pF	1	1	-4.5 V	4.5 V	16.5 V	170 MHz	5 V	20 V
Analog Devices Inc./Maxim Integrated ADGS1412BCPZ-RL7								-20 pC	100 mOhm	4 mm	24-LFCSP	4 mm	550 pA	SPST	NO	24-VFQFN Exposed Pad CSP	-100 dB	1.8 Ohms	Surface Mount	125 °C	-40 °C	190 ns	135 ns	4	23 pF	22 pF	1	1	-4.5 V	4.5 V	16.5 V	170 MHz	5 V	20 V
