PCIH Series

Catalog

POWER TO THE BOARD

Part	Mounting Type	Number of Rows	Connector Style	Connector Type	Color	Connector Usage	Number of Positions	Contact Finish	Power Contacts (Typical)	Signal Contacts (Typical)	Contact Finish Thickness	Contact Finish Thickness (string set options)	Contact Finish Thickness	Number of Positions Loaded	Termination	Current Rating	Operating Temperature (Max)	Operating Temperature (Min)	Material Flammability Rating
McGill Microwave Systems PCIH38F8000	Free Hanging (In-Line)	3	Backplane	Housing for Female Sockets	Blue	Receptacle	38
McGill Microwave Systems PCIH49W25F9300A1-246.3	Through Hole	3	CompactPCI®	Female Sockets Receptacle	Blue		49	Gold	25	24	0	Flash	Flash	All	Press-Fit
McGill Microwave Systems PCIH38F300A1/AA	Through Hole		CompactPCI®	Female Sockets Receptacle	Blue		38	Gold	15	23	0	Flash	Flash	All	Solder	40 A	125 °C	-55 °C	UL94 V-0
McGill Microwave Systems PCIH38M300A1	Through Hole	3	CompactPCI®	Header Male Pins	Blue		38	Gold	15	23	0	Flash	Flash	All	Solder
McGill Microwave Systems PCIH47F9300C1/AA	Through Hole		CompactPCI®	Female Sockets Receptacle	Blue		47	Gold	23	24	30 µin			All	Solder	40 A	125 °C	-55 °C	UL94 V-0
McGill Microwave Systems PCIH47F300D1-442.0	Through Hole	3	CompactPCI®	Female Sockets Receptacle	Blue		47	Gold	23	24	50 µin			All	Solder
McGill Microwave Systems PCIH47F400A1/AA-246.4	Right Angle Through Hole	3	CompactPCI®	Female Sockets Receptacle	Blue		47	Gold	23	24	0	Flash	Flash	All	Solder
McGill Microwave Systems PCIH47F9300D1-246.0	Through Hole	3	CompactPCI®	Female Sockets Receptacle	Blue		47	Gold	23	24	50 µin			All	Press-Fit
McGill Microwave Systems PCIH47F400C1	Right Angle Through Hole	3	CompactPCI®	Female Sockets Receptacle	Blue		47	Gold	23	24	30 µin			All	Solder
