RT06164 Series

Catalog

CONN CIRCULAR SKT 23 POS CRIMP ST CABLE MOUNT 23 TERMINAL 1 PORT

Part	Mounting Type	Number of Positions	Features	Shell Size - Insert Length	Shell Size - Insert Width	Material Flammability Rating	Shell Finish	Housing Color	Contact Type	Type	Orientation	Shielding	Shell Material	Fastening Type	Connector Type	Contact Size	Ingress Protection Description	Ingress Protection IP Rating	Insert Material	Contact Shape	Operating Temperature (Min)	Operating Temperature (Max)	Note	Includes	Includes Total Count	Primary Material
McGill Microwave Systems RT06164SNH	Free Hanging (In-Line)	4	Coupling Nut	16 mm	4 mm	UL94 V-0	Nickel	Silver	Crimp	For Female Sockets	N (Normal)	Shielded	Zinc Alloy	Bayonet Lock	Plug Housing	3.6 mm	Dust Tight Waterproof	IP67	Thermoplastic	Circular	-40 °C	105 °C	Contacts Not Included
McGill Microwave Systems RT06164PNH	Free Hanging (In-Line)	4	Coupling Nut	16 mm	4 mm	UL94 V-0	Nickel	Silver	Crimp	For Male Pins	N (Normal)	Shielded	Zinc Alloy	Bayonet Lock	Plug Housing	3.6 mm	Dust Tight Waterproof	IP67	Thermoplastic	Circular	-40 °C	105 °C	Contacts Not Included
McGill Microwave Systems RT06164SNH03	Free Hanging (In-Line)	4	Coupling Nut	16 mm	4 mm	UL94 V-0	Nickel	Silver	Crimp	For Female Sockets	N (Normal)	Shielded	Zinc Alloy	Bayonet Lock	Plug Housing	3.6 mm	Dust Tight Waterproof	IP67	Thermoplastic	Circular	-40 °C	125 °C	Contacts Not Included	Connector Gasket O-Ring	3 pcs
McGill Microwave Systems RT06164PNHEC03	Free Hanging (In-Line)	4	Coupling Nut	16 mm	4 mm	UL94 V-0	Nickel	Silver	Crimp	For Male Pins	N (Normal)	Shielded	Zinc Alloy	Bayonet Lock	Plug Housing	8	Dust Tight Waterproof	IP67	Thermoplastic	Circular	-40 °C	125 °C	Contacts Not Included			Metal
