ADM1281 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

HOT-SWAP CONTROLLER AND DIGITAL POWER AND ENERGY MONITOR WITH PMBUS INTERFACE

Part	Operating Temperature (Min)	Operating Temperature (Max)	Programmable Features	Applications	Features	Current - Supply	Package Width	Package Name	Package Length	Mounting Type	Number of Channels	Package / Case	Internal Switch(s)	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Type
Analog Devices Inc./Maxim Integrated ADM1281-3ACPZ-RL	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-2ACPZ-RL	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-1ACPZ	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-1ACPZ-RL	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-2ACPZ	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-1AACPZ	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-1AACPZ-RL	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
Analog Devices Inc./Maxim Integrated ADM1281-3ACPZ	-40 °C	85 °C	Circuit Breaker Current Limit Fault Timeout OVP UVLO	General Purpose	Auto Retry Fault Timeout Latched Fault OVP PMBus UVLO	5.5 mA	5 mm	32-LFCSP-WQ	5 mm	Surface Mount	1	32-WFQFN Exposed Pad CSP	No	4.5 V	20 V	Hot Swap Controller
