AD7988-1 Series

16-Bit Lower Power PulSAR ADCs in MSOP/LFCSP

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

16-Bit Lower Power PulSAR ADCs in MSOP/LFCSP

Part	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of A/D Converters	Package Name	Mounting Type	Number of Inputs	Data Interface	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Input Type	Sampling Rate (Per Second)	Architecture	Configuration	Reference Type	Package Length	Package Width	Number of Bits	Ratio - ADC	Ratio - S/H	Package / Case
Analog Devices Inc./Maxim Integrated AD7988-1BRMZ	2.375 V	2.625 V	1 count	10-MSOP 10-TFSOP	Surface Mount	1	DSP SPI	125 °C	-40 °C	2.375 V	2.625 V	Pseudo-Differential	100 kHz	SAR	S/H-ADC	External	0.118 in	3 mm	16 bits	1	1
Analog Devices Inc./Maxim Integrated AD7988-1BCPZ-RL7	2.375 V	2.625 V	1 count	10-LFCSP-WD	Surface Mount	1	DSP SPI	125 °C	-40 °C	2.375 V	2.625 V	Pseudo-Differential	100 kHz	SAR	S/H-ADC	External	3 mm	3 mm	16 bits	1	1	10-VFDFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD7988-1BRMZ-RL7	2.375 V	2.625 V	1 count	10-MSOP 10-TFSOP	Surface Mount	1	DSP SPI	125 °C	-40 °C	2.375 V	2.625 V	Pseudo-Differential	100 kHz	SAR	S/H-ADC	External	0.118 in	3 mm	16 bits	1	1

Catalog

16-Bit Lower Power PulSAR ADCs in MSOP/LFCSP

Description

The AD7988-1/AD7988-5are 16-bit, successive approximation, analog-to-digital converters (ADC) that operate from a single power supply, VDD. The AD7988-1 offers a 100 kSPS throughput, and the AD7988-5 offers a 500 kSPS throughput. They are low power, 16-bit sampling ADCs with a versatile serial interface port. On the CNV rising edge, they sample an analog input, IN+, between 0 V to VREFwith respect to a ground sense, IN−. The reference voltage, REF, is applied externally and can be set independent of the supply voltage, VDD.The SPI-compatible serial interface also features the ability to daisy-chain several ADCs on a single 3-wire bus using the SDI input. It is compatible with 1.8 V, 2.5 V, 3 V, or 5 V logic using the separate supply, VIO.The AD7988-1/AD7988-5 generics are housed in a 10-lead MSOP or a 10-lead LFCSP with operation specified from −40°C to +125°C.ApplicationsAutomated test equipmentData acquisition systemsMedical instrumentsMachine automation
