VQ23 Series

Catalog

GAS DETECT SENSOR, CH4, 50PPM, DIFFUSION ROHS COMPLIANT: YES

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Output	Current - Supply	Type	Operating Temperature (Min)	Operating Temperature (Max)	Housing Material	Screw Thread	Clamp Material	Clamp Plating	Screw Plating	Screw Material	Torque - Screw	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Mating Orientation	Color	Wire Termination	Pitch	Mounting Type	Current	Number of Levels	Positions Per Level	Voltage
McGill Microwave Systems VQ23TB	2.6 V	2.4 V	Voltage	335 mA	Hydrocarbons
McGill Microwave Systems VQ2311510000G						-40 °C	115 °C	Thermoplastic	M2	Brass	Nickel Plated	Zinc Plated	Steel	0.2 Nm	16 AWG	30 AWG	Horizontal with Board	Green	Rising Cage Clamp Screw	0.138 in	Press-Fit Through Hole	10 A	1	23	300 V
McGill Microwave Systems VQ2311500000G						-40 °C	115 °C	Thermoplastic	M2	Brass	Nickel Plated	Zinc Plated	Steel	0.2 Nm	16 AWG	30 AWG	Horizontal with Board	Green	Rising Cage Clamp Screw	0.138 in	Through Hole	10 A	1	23	300 V
