ADG1433 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

4 Ω RON, TRIPLE SPDT ±15 V/+12 V/±5 VICMOS™ SWITCH

Part	Crosstalk	Package Length	Package Name	Package Width	Operating Temperature (Max)	Operating Temperature (Min)	Switch Time Ton (Max)	Switch Time Toff (Max)	Voltage - Supply, Dual (Minimum)	Voltage - Supply, Dual (Nominal)	Voltage - Supply, Dual (Maximum)	Multiplexer Inputs	Demultiplexer Outputs	Voltage - Supply, Single (V+) (Maximum)	Voltage - Supply, Single (V+) (Minimum)	Number of Circuits	Switch Circuit Type	Current - Leakage (Max)	Mounting Type	Charge Injection	-3db Bandwidth	Channel Capacitance (CS(off))	Channel Capacitance (CD(off))	Channel-to-Channel Matching (ΔRon)	On-State Resistance (Max)	Package / Case
Analog Devices Inc./Maxim Integrated ADG1433YRUZ-REEL7	-70 dB	0.173 in	16-TSSOP	4.4 mm	125 °C	-40 °C	170 ns	75 ns	-4.5 V	4.5 V	16.5 V	2	1	16.5 V	5 V	3	SPDT	300 pA	Surface Mount	-50 pC	200 MHz	12 pF	22 pF	500 mOhm	4.7 Ohm
Analog Devices Inc./Maxim Integrated ADG1433YRUZ	-70 dB	0.173 in	16-TSSOP	4.4 mm	125 °C	-40 °C	170 ns	75 ns	-4.5 V	4.5 V	16.5 V	2	1	16.5 V	5 V	3	SPDT	300 pA	Surface Mount	-50 pC	200 MHz	12 pF	22 pF	500 mOhm	4.7 Ohm
Analog Devices Inc./Maxim Integrated ADG1433YCPZ-REEL	-70 dB	4 mm	16-LFCSP-VQ	4 mm	125 °C	-40 °C	170 ns	75 ns	-4.5 V	4.5 V	16.5 V	2	1	16.5 V	5 V	3	SPDT	300 pA	Surface Mount	-50 pC	200 MHz	12 pF	22 pF	500 mOhm	4.7 Ohm	16-VQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated ADG1433YRUZ-REEL	-70 dB	0.173 in	16-TSSOP	4.4 mm	125 °C	-40 °C	170 ns	75 ns	-4.5 V	4.5 V	16.5 V	2	1	16.5 V	5 V	3	SPDT	300 pA	Surface Mount	-50 pC	200 MHz	12 pF	22 pF	500 mOhm	4.7 Ohm
Analog Devices Inc./Maxim Integrated ADG1433YCPZ-REEL7	-70 dB	4 mm	16-LFCSP-VQ	4 mm	125 °C	-40 °C	170 ns	75 ns	-4.5 V	4.5 V	16.5 V	2	1	16.5 V	5 V	3	SPDT	300 pA	Surface Mount	-50 pC	200 MHz	12 pF	22 pF	500 mOhm	4.7 Ohm	16-VQFN Exposed Pad CSP
