AD9690 Series

Catalog

1-CHANNEL SINGLE ADC PIPELINED 1GSPS 14-BIT JESD204B 64-PIN LFCSP EP T/R

Part	Number of Bits	Voltage - Supply, Analog	Voltage - Supply, Analog	Mounting Type	Number of Inputs	Sampling Rate (Per Second)	Architecture	Voltage - Supply, Digital (Option 1)	Voltage - Supply, Digital (Option 2)	Data Interface	Input Type	Package / Case	Configuration	Package Width	Package Name	Package Length	Operating Temperature (Min)	Operating Temperature (Max)	Ratio - ADC	Ratio - S/H	Number of A/D Converters	Reference Type
Analog Devices Inc./Maxim Integrated AD9690BCPZRL7-1000	14 bits	1.25V 2.5V	1.25 V 2.5 V	Surface Mount	1	500 MHz	Pipelined	1.25 V	1.8 V	JESD204B	Differential	64-WFQFN Exposed Pad CSP	S/H-ADC	9 mm	64-LFCSP	9 mm	-40 °C	85 °C	1	1	1 count	Internal
Analog Devices Inc./Maxim Integrated AD9690BCPZ-500	14 bits	1.25V 2.5V	1.25 V 2.5 V	Surface Mount	1	500 MHz	Pipelined	1.25 V	1.8 V	JESD204B	Differential	64-WFQFN Exposed Pad CSP	S/H-ADC	9 mm	64-LFCSP	9 mm	-40 °C	85 °C	1	1	1 count	Internal
Analog Devices Inc./Maxim Integrated AD9690BCPZRL7-500	14 bits	1.25V 2.5V	1.25 V 2.5 V	Surface Mount	1	500 MHz	Pipelined	1.25 V	1.8 V	JESD204B	Differential	64-WFQFN Exposed Pad CSP	S/H-ADC	9 mm	64-LFCSP	9 mm	-40 °C	85 °C	1	1	1 count	Internal
Analog Devices Inc./Maxim Integrated AD9690BCPZ-1000	14 bits	1.25V 2.5V	1.25 V 2.5 V	Surface Mount	1	1 GHz	Pipelined	1.25 V	1.8 V	JESD204B	Differential	64-WFQFN Exposed Pad CSP	S/H-ADC	9 mm	64-LFCSP	9 mm	-40 °C	85 °C	1	1	1 count	Internal
