M12A-08PMMS Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
SENSOR CABLE, A CODE, M12 SENSOR STRAIGHT PLUG, FREE END, 8 POSITIONS, 300 MM, 11.8 ", M SERIES
| Part | 1st Connector Type | 1st Connector Shell Size - Insert | Color | 1st Connector Number of Positions Loaded | Ingress Protection Description | Ingress Protection IP Rating | 1st Connector Mounting Type | Usage | Cable Type | 1st Connector Gender | 1st Connector Orientation | Assembly Configuration | Length | 2nd Connector Type | 1st Connector Number of Positions | Shielding | Connector Type | Orientation | Contact Material | Fastening Type | Primary Material | Insert Material | Shell Finish | Mounting Feature | Shell Material | Mounting Type | Number of Positions | Shell Size - Insert | Termination | Contact Finish - Mating | Operating Temperature (Max) | Operating Temperature (Min) | Voltage Rating | Voltage Rating (Type) | Current Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Receptacle | M12 | Multiple | All | Dust Tight Water Resistant Waterproof | IP68 IP69K | Panel Mount | Industrial Environments | Individual | Male Pins | A | Standard | 0.98 ft | Wire Leads | 8 positions | Unshielded | |||||||||||||||||||
McGill Microwave Systems | Silver | Dust Tight Water Resistant Waterproof | IP68 IP69K | Shielded | Male Pins Plug | A | Copper Alloy | Threaded | Metal | Glass Filled Nylon PA Polyamide | Nickel | Bulkhead Rear Side Nut | Zinc Alloy | Panel Mount | 8 | M12-8 | Wire Leads | Gold | 85 °C | -25 °C | 30 V | AC DC | 2 A | ||||||||||||
 McGill Microwave Systems | Silver | Dust Tight Water Resistant Waterproof | IP68 IP69K | Shielded | Male Pins Plug | A | Copper Alloy | Threaded | Metal | Glass Filled Nylon PA Polyamide | Nickel | Bulkhead Front Side Nut | Zinc Alloy | Panel Mount | 8 | M12-8 | Wire Leads | Gold | 85 °C | -25 °C | 30 V | AC DC | 2 A | ||||||||||||
 McGill Microwave Systems | Silver | Dust Tight Water Resistant Waterproof | IP68 IP69K | Shielded Unshielded | Male Pins Plug | A | Copper Alloy | Threaded | Metal | Glass Filled Nylon PA Polyamide | Nickel | Bulkhead Front Side Nut | Zinc Alloy | Panel Mount | 8 | M12-8 | Solder Cup | Gold | 85 °C | -40 °C | 30 V | AC DC | 2 A | ||||||||||||
 McGill Microwave Systems | Silver | Dust Tight Water Resistant Waterproof | IP68 IP69K | Shielded | Male Pins Plug | A | Copper Alloy | Threaded | Metal | Glass Filled Nylon PA Polyamide | Nickel | Bulkhead Front Side Nut | Zinc Alloy | Panel Mount | 8 | M12-8 | Solder Cup | Gold | 85 °C | -40 °C | 30 V | AC DC | 2 A | ||||||||||||
 McGill Microwave Systems | Silver | Dust Tight Water Resistant Waterproof | IP68 IP69K | Shielded | Male Pins Plug | A | Copper Alloy | Threaded | Metal | Glass Filled Nylon PA Polyamide | Nickel | Bulkhead Rear Side Nut | Zinc Alloy | Panel Mount | 8 | M12-8 | Solder Cup | Gold | 85 °C | -40 °C | 30 V | AC DC | 2 A |
