ISL54053 Series
Manufacturer: Renesas Electronics Corporation
Beta
⌘K
ULTRA LOW ON-RESISTANCE, LOW VOLTAGE, SINGLE SUPPLY, SPDT ANALOG SWITCH
| Part | Switch Time Toff (Max) | Switch Time Ton (Max) | On-State Resistance (Typ) | Crosstalk | Switch Circuit Type | Mounting Type | Voltage - Supply, Single (V+) (Minimum) | Voltage - Supply, Single (V+) (Maximum) | Channel Capacitance (CS(off)) | Channel Capacitance (CD(off)) | -3db Bandwidth | Package Name | Package Length | Package Width | Number of Circuits | Current - Leakage (Max) | Package / Case | Operating Temperature (Max) | Operating Temperature (Min) | Multiplexer Inputs | Demultiplexer Outputs | Channel-to-Channel Matching (ΔRon) | Charge Injection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Renesas Electronics Corporation | 10 ns | 24 ns | 860 mOhm | -83 dB | SPDT | Surface Mount | 1.8 V | 5.5 V | 16 pF | 16 pF | 190 MHz | 6-UTDFN | 1.2 mm | 1 mm | 1 | 10 nA | 6-UFDFN | 85 °C | -40 °C | 2 | 1 | 4 mOhm | 26 pC |
Renesas Electronics Corporation | 10 ns | 24 ns | 860 mOhm | -83 dB | SPDT | Surface Mount | 1.8 V | 5.5 V | 16 pF | 16 pF | 190 MHz | 6-SOT | 1 | 10 nA | SOT-23-6 | 85 °C | -40 °C | 2 | 1 | 4 mOhm | 26 pC |
