V718 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; SOCKET; FEMALE; 10A; 300V

Part	Contact Mating Finish	Number of Levels	Current - UL	Operating Temperature (Min)	Operating Temperature (Max)	Positions Per Level	Header Orientation Angle	Header Orientation	Type	Color	Number of Positions	Voltage - UL	Termination Style	Features	Pitch	Mounting Type	Housing Material	Contact Material	Insulation Height	Contact Tail Length	Material Flammability Rating
McGill Microwave Systems V71872510000G	Tin	1	10 A	-40 °C	115 °C	18	90 °	Right Angle	Female Sockets Header	Green	18	300 V	Solder	Mating Flange Retention Latches	0.197 in	Through Hole	Thermoplastic	Phosphor Bronze	0.425 in	0.138 in	UL94 V-0
McGill Microwave Systems V71811500000G	Tin	1	4 A	-40 °C	115 °C	18		Vertical	Female Sockets Header	Green	18	300 V	Solder		0.138 in	Through Hole	Thermoplastic	Phosphor Bronze	0.571 in	0.134 in	UL94 V-0
McGill Microwave Systems V71812510000G	Tin	1	4 A	-40 °C	115 °C	18	90 °	Right Angle	Female Sockets Header	Green	18	300 V	Solder	Mating Flange	0.138 in	Through Hole	Thermoplastic	Phosphor Bronze	0.268 in	0.134 in	UL94 V-0
McGill Microwave Systems V71832500000G	Tin	1	8 A	-40 °C	115 °C	18		Vertical	Female Sockets Header	Green	18	300 V	Solder	Mating Flange	0.15 in	Through Hole	Thermoplastic	Phosphor Bronze	0.571 in	0.134 in	UL94 V-0
McGill Microwave Systems V71812500000G	Tin	1	4 A	-40 °C	115 °C	18		Vertical	Female Sockets Header	Green	18	300 V	Solder	Mating Flange	0.138 in	Through Hole	Thermoplastic	Phosphor Bronze	0.571 in	0.134 in	UL94 V-0
McGill Microwave Systems V71811510000G	Tin	1	4 A	-40 °C	115 °C	18	90 °	Right Angle	Female Sockets Header	Green	18	300 V	Solder		0.138 in	Through Hole	Thermoplastic	Phosphor Bronze	0.26 in	0.134 in	UL94 V-0
McGill Microwave Systems V71872500000G	Tin	1	10 A	-40 °C	115 °C	18		Vertical	Female Sockets Header	Green	18	300 V	Solder	Mating Flange Retention Latches	0.197 in	Through Hole	Thermoplastic	Phosphor Bronze	0.748 in	0.138 in	UL94 V-0
McGill Microwave Systems V71831510000G	Tin	1	8 A	-40 °C	115 °C	18	90 °	Right Angle	Female Sockets Header	Green	18	300 V	Solder		0.15 in	Through Hole	Thermoplastic	Phosphor Bronze	0.26 in	0.134 in	UL94 V-0
McGill Microwave Systems V71831500000G	Tin	1	8 A	-40 °C	115 °C	18		Vertical	Female Sockets Header	Green	18	300 V	Solder		0.15 in	Through Hole	Thermoplastic	Phosphor Bronze	0.571 in	0.134 in	UL94 V-0
McGill Microwave Systems V71851510000G	Tin	1	20 A	-40 °C	115 °C	18	90 °	Right Angle	Female Sockets Header	Green	18	300 V	Solder	Retention Latches	5.08 mm	Through Hole	Thermoplastic	Copper		0.138 in	UL94 V-0
