043160 Series
Manufacturer: Molex
Beta
⌘K
CONN WIRE TO BOARD HDR 4 POS 7.5MM SOLDER ST TOP ENTRY THRU-HOLE BAG
| Part | Features | Number of Positions | Connector Type | Mounting Type | Number of Rows | Color | Termination | Pitch | Contact Finish | Fastening Type | Current Rating | Operating Temperature (Max) | Operating Temperature (Min) | Contact Material | Contact Finish Thickness | Voltage Rating | Material - Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Board Lock | 4 | Header Male Blades | Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 4 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 3 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 5 | Header Male Blades | Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 6 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | 5 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide | |
 Molex | Board Lock | 6 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 5 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | Board Lock | 2 | Header Male Blades | Right Angle Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
 Molex | 3 | Header Male Blades | Through Hole | 1 | Black | Solder | 0.295 in | Tin | Locking Ramp | 18 A | 75 °C | -40 °C | Brass | 60 µin | 600 V | Glass Filled Nylon 4/6 PA46 Polyamide |
