796642 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN SHROUDED HEADER (4 SIDES) M 10 POS 5MM SOLDER ST TOP ENTRY THRU-HOLE BOX
| Part | Voltage - UL | Number of Levels | Pitch | Current - UL | Mounting Type | Header Orientation | Positions Per Level | Contact Mating Finish | Operating Temperature (Min) | Operating Temperature (Max) | Number of Positions | Color | Type | Termination Style | Insulation Height | Contact Material | Housing Material | Contact Tail Length | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 10 | Tin | -40 °C | 110 °C | 10 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 3 | Tin | -40 °C | 110 °C | 3 | Green | Header Male Pins Shrouded (4 Side) | Solder | |||||
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 7 | Tin | -40 °C | 110 °C | 7 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 22 | Tin | -40 °C | 110 °C | 22 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 5 | Tin | -40 °C | 110 °C | 5 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 12 | Tin | -40 °C | 110 °C | 12 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 4 | Tin | -40 °C | 110 °C | 4 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 3 | Tin | -40 °C | 110 °C | 3 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
 TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 8 | Tin | -40 °C | 110 °C | 8 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
TE Connectivity AMP Connectors | 300 V | 1 | 0.197 in | 15 A | Through Hole | Vertical | 17 | Tin | -40 °C | 110 °C | 17 | Green | Header Male Pins Shrouded (4 Side) | Solder | 0.472 in | Copper Alloy | Nylon 6/6 PA66 Polyamide | 0.138 in | UL94 V-0 |
