EX-11 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
SENSOR THROUGH-BEAM 15CM PNP
| Part | Output Configuration | Sensing Distance | Cable Length | Ingress Protection | Light Source | Operating Temperature (Min) | Operating Temperature (Max) | Response Time | Connection Method | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Sensing Method |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | Dark-ON PNP - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Dark-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 118.1 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Dark-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
 Panasonic Industrial Automation Sales | Light-ON NPN - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
Panasonic Industrial Automation Sales | Light-ON PNP - Open Collector | 5.9 " | 78.74 in | IP67 | Red LED | -25 °C | 55 °C | 500 µs | Cable | 12 VDC | 24 VAC | Through-Beam |
