60251 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SPADE TERMINAL 18-14 AWG TPBR
| Part | Terminal Type | Contact Finish | Insulation | Wire Gauge (AWG) (Max) | Wire Gauge (AWG) (Min) | Mounting Type | Stud/Tab Size | Contact Material | Termination | Length - Overall | Width - Outer Edges | Length - Termination | Tongue Inside Opening | Length - Ring Center to Termination | Insulation Diameter (Max) | Insulation Diameter (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Standard | Tin | Non-Insulated | 18 AWG | 14 AWG | Free Hanging (In-Line) | 8 Stud | Brass | Crimp | 0.645 in | 0.312 in | 0.311 in | 0.171 in | 0.209 in | 0.18 in | 0.13 in |
