DSC8103 Series

Catalog

OSCILLATOR, PROGRAMMABLE, 10 MHZ TO 460 MHZ, 10 PPM, 3.3 V, LVDS, SMD, 3.2MM X 5MM

Part	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Size / Dimension Width	Size / Dimension Length	Function	Ratings	Programmable Type	Base Resonator	Package / Case	Frequency Stability (Total)	Output	Type	Current - Supply (Max)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Available Frequency Range (Minimum)	Available Frequency Range (Maximum)	Height - Seated (Max)	Current - Supply (Disable) (Max)	Package Width	Package Name	Package Length	Frequency Stability
Microchip Technology DSC8103CI5	Surface Mount	-40 °C	85 °C	0.098 in	0.126 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-SMD No Lead	10 ppm	LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in
Microchip Technology DSC8103BL5	Surface Mount			0.126 in	0.197 in	Standby		Blank (User Must Program)	MEMS	6-VDFN		LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in	95 µA	3.2 mm	6-CDFN	5 mm	10 ppm
Microchip Technology DSC8103CI2	Surface Mount	-40 °C	85 °C	0.098 in	0.126 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-SMD No Lead	25 ppm	LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in
Microchip Technology DSC8103BI2	Surface Mount	-40 °C	85 °C	0.126 in	0.197 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-VDFN	25 ppm	LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in		3.2 mm	6-CDFN	5 mm
Microchip Technology DSC8103AI2	Surface Mount	-40 °C	85 °C	0.197 in	0.276 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-SMD No Lead	25 ppm	LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in
Microchip Technology DSC8103DI2T	Surface Mount	-40 °C	85 °C	0.079 in	0.098 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-SMD No Lead		LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in	95 µA				25 ppm
Microchip Technology DSC8103AI2T	Surface Mount	-40 °C	85 °C	0.197 in	0.276 in	Standby		Blank (User Must Program)	MEMS	6-SMD No Lead Exposed Pad		LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in	95 µA				25 ppm
Microchip Technology DSC8103DI2	Surface Mount	-40 °C	85 °C	0.079 in	0.098 in	Standby	AEC-Q100	Blank (User Must Program)	MEMS	6-SMD No Lead		LVDS	XO (Standard)	32 mA	3.6 V	2.25 V	10 MHz	460 MHz	0.035 in	95 µA				25 ppm
