QN9090 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
BLUETOOTH LOW ENERGY MCU 1.9V TO 3.6V 3.4MBPS 40-PIN HVQFN T/R
| Part | Mounting Type | Type | Sensitivity | Package / Case | Data Rate (Max) | Protocol | Memory Type | Memory Size (Flash) | Serial Interfaces | Current - Receiving | Power - Output | RF Family/Standard | Current - Transmitting (Max) | Current - Transmitting (Min) | Package Length | Package Name | Package Width | Frequency | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Operating Temperature (Max) | Operating Temperature (Min) | Supplied Contents | For Use With/Related Products | Utilized IC / Part | Contents | GPIO Count |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
 NXP USA Inc. | Bluetooth® 5.x (BLE) Transceiver | 2.4 GHz | Board(s) | QN9090 | QN9090 | Board | |||||||||||||||||||||
 NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | I2C PWM SPI UART | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 2.4 GHz | 1.9 V | 3.6 V | 125 °C | -40 °C | |||||
NXP USA Inc. | Surface Mount | TxRx + MCU | -97 dBm | 40-VFQFN Exposed Pad | 2 MBaud | Bluetooth v5.0 | Flash RAM | 640 kB | ADC GPIO I2C PWM SPI UART USART USB | 4.3 mA | 11 dBm | Bluetooth | 20.3 mA | 7.4 mA | 6 mm | 40-HVQFN | 6 mm | 1.9 V | 3.6 V | 125 °C | -40 °C | 22 |
