F923LS Series

Catalog

OS2 2F 3MM PC LSZH SC DUP / SC DUP STD P

Part	Operating Temperature (Max)	Operating Temperature (Min)	Color - Cable	Bend Radius	Return Loss	Color - Connectors	Insertion Loss	Jacket (Insulation) Material	Fiber Core Diameter	Fiber Cladding Diameter	2nd Connector	Type	Length - Overall	Cable Diameter	Cable Type	1st Connector
Panduit Corp F923LSNSNSNM011	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	36.1 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM048	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	157.5 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM026	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	85.3 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM3.5	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	11.5 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM030	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	98.4 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM046	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	150.9 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM1.5	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	4.9 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM023	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	75.5 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM005	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	13.1 ft	0.12 "	Buffered Fiber	SC Duplex
Panduit Corp F923LSNSNSNM049	70 °C	-20 °C	Yellow	29 mm	55 dB	Black	0.5 dB	Low Smoke Zero Halogen (LSZH)	9 µm	125 µm	SC Duplex	Duplex OS2 Singlemode	160.8 ft	0.12 "	Buffered Fiber	SC Duplex
