ISL6561 Series

Catalog

MULTIPHASE PWM CONTROLLER WITH PRECISION RDS, ON OR DCR CURRENT SENSING

Part	Package Width	Package Name	Package Length	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Number of Outputs	Voltage - Output (Max)	Voltage - Output (Min)	Package / Case	Applications	Voltage - Input (Maximum)	Voltage - Input (Minimum)
Renesas Electronics Corporation ISL6561IRZ	6 mm	40-QFN	6 mm	Surface Mount	-40 °C	85 °C	4	1.6 V	0.84 V	40-VFQFN Exposed Pad	Controller Intel VR10X	12 V	3 V
Renesas Electronics Corporation ISL6561CRZ-TK	6 mm	40-QFN	6 mm	Surface Mount	0 °C	70 °C	4	1.6 V	0.84 V	40-VFQFN Exposed Pad	Controller Intel VR10X	12 V	3 V
Renesas Electronics Corporation ISL6561CR	6 mm	40-QFN	6 mm	Surface Mount	0 °C	70 °C	4	1.6 V	0.84 V	40-VFQFN Exposed Pad	Controller Intel VR10X	12 V	3 V
Renesas Electronics Corporation ISL6561CR-T	6 mm	40-QFN	6 mm	Surface Mount	0 °C	70 °C	4	1.6 V	0.84 V	40-VFQFN Exposed Pad	Controller Intel VR10X	12 V	3 V
Renesas Electronics Corporation ISL6561IRZ-T	6 mm	40-QFN	6 mm	Surface Mount	-40 °C	85 °C	4	1.6 V	0.84 V	40-VFQFN Exposed Pad	Controller Intel VR10X	12 V	3 V
