T37111 Series
Manufacturer: Curtis Industries
Beta
⌘K
CONN BARRIER STRP 12CIRC 0.375"
| Part | Mounting Type | Operating Temperature | Material - Insulation | Material Flammability Rating | Terminal Block Type | Number of Circuits | Pitch | Number of Rows | Bottom Termination | Top Termination | Barrier Type | Number of Wire Entries | Wire Gauge (AWG) (Min) | Wire Gauge (AWG) (Max) | Voltage Rating | Current Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Curtis Industries | Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 12 | 0.375 in | 1 | PC Pin | Screws | 2 Wall (Dual) | 12 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 17 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 17 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 18 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 18 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
 Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 2 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 2 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 10 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 10 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 26 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 26 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 9 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 9 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 11 | 0.375 in | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 11 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
Curtis Industries | Chassis Panel Through Hole | 105 °C | Polypropylene PP | UL94 V-0 | Barrier Block | 1 | 1 | PC Pin | Screws with Captive Plate | 3 Wall (Tri) | 1 | 12 AWG | 22 AWG | 300 VAC/DC | 20 A |
