044441 Series
Manufacturer: Molex
Beta
⌘K
CONN HOUSING RCP 3 POS 7.49MM CRIMP ST CABLE MOUNT NATURAL SABRE™ BAG
| Part | Number of Rows | Stacking Direction | Color | Contact Termination | Contact Type | Number of Positions | Mounting Type | Connector Type | Pitch | Current Rating | Fastening Type | Note | Operating Temperature (Max) | Operating Temperature (Min) | Material - Insulation | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 1 | Side to Side | Natural | Crimp | Female Blade Socket | 3 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Side to Side | Black | Crimp | Female Blade Socket | 5 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Side to Side | Black | Crimp | Female Blade Socket | 3 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Side to Side | Natural | Crimp | Female Blade Socket | 2 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Black | Crimp | Female Blade Socket | 3 | Free Hanging (In-Line) | Receptacle | 0.295 in | 10 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | 600 V | |
 Molex | 1 | Black | Crimp | Female Blade Socket | 2 | Free Hanging (In-Line) | Receptacle | 0.295 in | 10 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | 600 V | |
 Molex | 1 | Side to Side | Natural | Crimp | Female Blade Socket | 4 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Black | Crimp | Female Blade Socket | 5 | Free Hanging (In-Line) | Receptacle | 0.295 in | 10 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | 600 V | |
 Molex | 1 | Side to Side | Natural | Crimp | Female Blade Socket | 6 | Free Hanging (In-Line) | Receptacle | 0.295 in | 18 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | |
 Molex | 1 | Black | Crimp | Female Blade Socket | 4 | Free Hanging (In-Line) | Receptacle | 0.295 in | 10 A | Latch Lock | Contacts Not Included | 75 °C | -40 °C | Nylon PA Polyamide | 600 V |
