25LC128 Series

Catalog

EEPROM, 128 KBIT, 16K X 8BIT, SPI, 10 MHZ, TSSOP, 8 PINS

Part	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Package Length	Package Name	Package Width	Memory Depth	Memory Width	Technology	Memory Type	Operating Temperature (Max)	Operating Temperature (Min)	Memory Size	Mounting Type	Memory Interface (Type)	Memory Format	Clock Frequency	Write Cycle Time - Word	Write Cycle Time - Page	Package / Case
Microchip Technology 25LC128-I/ST	2.5 V	5.5 V	0.173 in	8-TSSOP	4.4 mm	16 K	8 bit	EEPROM	Non-Volatile	85 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128T-E/SM	2.5 V	5.5 V	0.209 in	8-SOIC 8-SOIJ	5.3 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128T-E/ST	2.5 V	5.5 V	0.173 in	8-TSSOP	4.4 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128T-H/SN	2.5 V	5.5 V	0.154 in	8-SOIC	3.9 mm	16 K	8 bit	EEPROM	Non-Volatile	150 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	5 MHz	6 ms	6 ms
Microchip Technology 25LC128-E/SN	2.5 V	5.5 V	0.154 in	8-SOIC	3.9 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128-E/P	2.5 V	5.5 V	0.3 in	8-DIP 8-PDIP	7.62 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Through Hole	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128-E/ST	2.5 V	5.5 V	0.173 in	8-TSSOP	4.4 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
Microchip Technology 25LC128-I/MF	2.5 V	5.5 V	6 mm	8-DFN-S	5 mm	16 K	8 bit	EEPROM	Non-Volatile	85 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms	8-VDFN Exposed Pad
Microchip Technology 25LC128-E/MF	2.5 V	5.5 V	6 mm	8-DFN-S	5 mm	16 K	8 bit	EEPROM	Non-Volatile	125 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms	8-VDFN Exposed Pad
Microchip Technology 25LC128T-I/SM	2.5 V	5.5 V	0.209 in	8-SOIC 8-SOIJ	5.3 mm	16 K	8 bit	EEPROM	Non-Volatile	85 °C	-40 °C	16 KB	Surface Mount	SPI	EEPROM	10 MHz	5 ms	5 ms
