6600303 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
MBXL VERT HDR 3ACP
| Part | Connector Style | Connector Type | Contact Finish Thickness | Pitch | Mounting Type | Features | Power Contacts (Typical) | Termination | Number of Rows | Number of Positions Loaded | Color | Contact Finish | Number of Positions | Current Rating | Material Flammability Rating | Voltage Rating | Voltage Rating (Type) | Operating Temperature (Min) | Operating Temperature (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Multi-Beam | Header Male Blades | 3 µin | 0.3 in | Through Hole | Board Lock Mating Guide | 3 | Press-Fit | 1 | All | Black | Gold | 3 | 42 A | UL94 V-0 | 300 VAC/DC | DC | -20 °C | 105 °C |
 TE Connectivity AMP Connectors | |||||||||||||||||||
TE Connectivity AMP Connectors | Multi-Beam | Header Male Blades | 3 µin | 0.25 in | Through Hole | Board Lock Mating Guide | 4 | Press-Fit | 1 | All | Black | Gold | 4 | 42 A | UL94 V-0 | 200 VDC | DC | -20 °C | 105 °C |
 TE Connectivity AMP Connectors | Multi-Beam | Header Male Blades | 30 µin | 0.3 in | Through Hole | Board Lock Mating Guide | 8 | Press-Fit | All | Black | Gold | 8 | UL94 V-0 | -20 °C | 105 °C |
