ICL7621 Series

Catalog

IC CMOS 2 CIRCUIT 8DIP

Part	Package Name	Slew Rate	Voltage - Supply Span (Max)	Package Length	Package Width	Current - Output / Channel	Operating Temperature (Max)	Mounting Type	Voltage - Input Offset	Voltage - Supply Span (Min)	Number of Circuits	Current - Supply	Gain Bandwidth Product	Amplifier Type	Current - Input Bias
Renesas Electronics Corporation ICL7621DCPA	8-DIP 8-PDIP	0.16 V/µs	16 V	0.3 in	7.62 mm	1 mA	70 °C	Through Hole	15 mV	2 V	2	100 µA	1.4 MHz	CMOS	1 pA
Renesas Electronics Corporation ICL7621DCPAZ	8-DIP 8-PDIP	0.16 V/µs	16 V	0.3 in	7.62 mm	1 mA	70 °C	Through Hole	15 mV	2 V	2	100 µA	480 kHz	CMOS	1 pA
Renesas Electronics Corporation ICL7621DCBA-T	8-SOIC	0.16 V/µs	16 V	0.154 in	3.9 mm	1 mA	70 °C	Surface Mount	15 mV	2 V	2	100 µA	480 kHz	CMOS	1 pA
Renesas Electronics Corporation ICL7621DCBAZ	8-SOIC	0.16 V/µs	16 V	0.154 in	3.9 mm	1 mA	70 °C	Surface Mount	15 mV	2 V	2	100 µA	480 kHz	CMOS	1 pA
Renesas Electronics Corporation ICL7621DCBA	8-SOIC	0.16 V/µs	16 V	0.154 in	3.9 mm	1 mA	70 °C	Surface Mount	15 mV	2 V	2	100 µA	480 kHz	CMOS	1 pA
