AD8555 Series

Catalog

IC OPAMP ZER-DRIFT 1CIRC 16LFCSP

Part	Package Width	Package Name	Package Length	Voltage - Input Offset	Current - Supply	Slew Rate	Voltage - Supply Span (Min)	Amplifier Type	Mounting Type	Current - Output / Channel	Package / Case	Voltage - Supply Span (Max)	Gain Bandwidth Product	Number of Circuits	Operating Temperature (Max)	Operating Temperature (Min)	Current - Input Bias
Analog Devices Inc./Maxim Integrated AD8555ACPZ-REEL	4 mm	16-LFCSP-VQ	4 mm	2 µV	2 mA	1.2 V/µs	2.7 V	Zero-Drift	Surface Mount	10 mA	16-VQFN Exposed Pad CSP	5.5 V	2 MHz	1	125 °C	-40 °C	16 nA
Analog Devices Inc./Maxim Integrated AD8555ACPZ-R2	4 mm	16-LFCSP-VQ	4 mm	2 µV	2 mA	1.2 V/µs	2.7 V	Zero-Drift	Surface Mount	10 mA	16-VQFN Exposed Pad CSP	5.5 V	2 MHz	1	125 °C	-40 °C	16 nA
Analog Devices Inc./Maxim Integrated AD8555ARZ-REEL	3.9 mm	8-SOIC	0.154 in	2 µV	2 mA	1.2 V/µs	2.7 V	Zero-Drift	Surface Mount	10 mA		5.5 V	2 MHz	1	125 °C	-40 °C	16 nA
Analog Devices Inc./Maxim Integrated AD8555ACP-R2	4 mm	16-LFCSP-VQ	4 mm	2 µV	2 mA	1.2 V/µs	2.7 V	Chopper (Zero-Drift)	Surface Mount	10 mA	16-VQFN Exposed Pad CSP	5.5 V	2 MHz	1	125 °C	-40 °C	16 nA
