PIC24HJ128GP204 Series

Catalog

16 BIT MICROCONTROLLER, PIC24 FAMILY PIC24HJGP SERIES MICROCONTROLLERS, PIC24, 16 BIT, 80 MHZ

Part	Package Length	Package Name	Package Width	Qualification	Oscillator Type	Core Processor	A/D Resolution (bits)	A/D Channels	Connectivity	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	RAM Size Width	RAM Size Depth	Speed	Program Memory Size	Program Memory Depth	Program Memory Width	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Number of I/O	Peripherals	Package / Case	Core Size (Bit Width)	Grade	Program Memory Type
Microchip Technology PIC24HJ128GP204-E/ML	8 mm	44-QFN	8 mm	AEC-Q100	Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	125 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-VQFN Exposed Pad	16 Bit	Automotive	FLASH
Microchip Technology PIC24HJ128GP204T-I/ML	8 mm	44-QFN	8 mm		Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	85 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-VQFN Exposed Pad	16 Bit		FLASH
Microchip Technology PIC24HJ128GP204-I/PT	10 mm	44‑TQFP	10 mm		Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	85 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-TQFP	16 Bit		FLASH
Microchip Technology PIC24HJ128GP204-E/PT	10 mm	44‑TQFP	10 mm	AEC-Q100	Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	125 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-TQFP	16 Bit	Automotive	FLASH
Microchip Technology PIC24HJ128GP204T-I/PT	10 mm	44‑TQFP	10 mm		Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	85 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-TQFP	16 Bit		FLASH
Microchip Technology PIC24HJ128GP204-I/ML	8 mm	44-QFN	8 mm		Internal	PIC	10 bit 12 bit	13 count	I2C IrDA LINbus PMP SPI UART USART	3.6 V	3 V	8 bit	8 K	40 MIPs	128 KB	43 K	24	Surface Mount	85 °C	-40 °C	35	Brown-out Detect DMA POR PWM Reset WDT	44-VQFN Exposed Pad	16 Bit		FLASH

Catalog

Description

The PIC24H 16-bit device family employs a powerful 16-bit architecture, ideal for applications that rely on high-speed, repetitive computations, as well as control. The devices are pin compatible with the dsPIC33F family of devices, and share a very high degree of compatibility with the dsPIC30F family devices. This allows seamless migration options from/to PIC24F, dsPIC30F and dsPIC33F devices.
