24812-01-BX Series

SOL 12V 7.7OHM CONT #8

Catalog

SOL 12V 7.7OHM CONT #8

Part	Contact Material	Coil Type	Operating Temperature (Max)	Operating Temperature (Min)	Form A Count	Contact Form	Termination Style	Contact Rating (Current)	Coil Current	Switching Voltage DC (Max)	Coil Voltage	Relay Type	Mounting Type
LITTELFUSE 24812-01-BX	Silver (Ag)	Non Latching	60 °C	-40 °C	1	SPST-NO	Stud	225 A	1.6 A	14 VDC	12 VAC	General Purpose	Chassis Mount

Catalog

SOL 12V 7.7OHM CONT #8

Description

Designed for heavy-duty vehicles and large machinery, this Plastic-Body Continuous-Duty SPST Series Heavy-Duty Solenoid Relay (24812-01-BX) features a 225 A continuous current rating and an insulated 12 V coil with stud terminals and a coil impedance of 7.7 ohms. The individually boxed Cole Hersee solenoid relay has silver contacts and an L-style metal bracket.
