3-PHASE VOLTAGE MONITOR/ 190-4

Part	Melting I²t	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Voltage Rating - AC	Current Rating	Package Name	Package Length	Package Width	Breaking Capacity	Mounting Type	Response Time	Approval Agency	Fuse Type	Operating Temperature (Max)	Operating Temperature (Min)	Trip Status	Contact Rating (Current)	Circuit	Delay Time Mode	Delay Time (Minimum)	Delay Time (Maximum)	Delay Time (Fixed)	Trip Voltage (Max)	Trip Voltage (Min)	Output Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Type	Package / Case
LITTELFUSE 0202.750H	0.098	0.165 in	0.372 in	0.25 in	250 V	0.75 A	2-DIP	10.16 mm	10.16 mm	50 A	Through Hole	Fast Blow	CSA UL	Board Mount (Cartridge Style Excluded)	125 °C	-55 °C
LITTELFUSE 0202005.H	4.68	0.165 in	0.372 in	0.25 in	250 V	5 A	2-DIP	10.16 mm	10.16 mm	50 A	Through Hole	Fast Blow	CSA UL	Board Mount (Cartridge Style Excluded)	125 °C	-55 °C
LITTELFUSE 202											Chassis Mount				70 °C	-40 °C	Energized High Low	10 A	SPDT (1 Form C)	Fixed	2 Sec	4 Sec	2 Sec	480 V	190 V	Relay	480 VAC	190 VAC	Voltage Asymmetry Voltage Sensing AC
LITTELFUSE 020201.5URG	0.54	0.165 in	0.372 in	0.25 in	250 V	1.5 A				50 A	Surface Mount	Fast Blow	CSA UL	Board Mount (Cartridge Style Excluded)	125 °C	-55 °C														2-SMD Gull Wing
