V722 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; SOCKET; FEMALE; 10A; 300V

Part	Termination Style	Pitch	Features	Number of Positions	Color	Mounting Type	Voltage - UL	Positions Per Level	Operating Temperature (Min)	Operating Temperature (Max)	Contact Mating Finish	Current - UL	Type	Number of Levels	Header Orientation Angle	Header Orientation	Housing Material	Contact Tail Length	Material Flammability Rating	Insulation Height	Contact Material
McGill Microwave Systems V72272510000G	Solder	0.197 in	Mating Flange Retention Latches	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	10 A	Female Sockets Header	1	90 °	Right Angle	Thermoplastic	0.138 in	UL94 V-0	0.425 in	Phosphor Bronze
McGill Microwave Systems V72232500000G	Solder	0.15 in	Mating Flange	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	8 A	Female Sockets Header	1		Vertical	Thermoplastic	0.134 in	UL94 V-0	0.571 in	Phosphor Bronze
McGill Microwave Systems V72252500000G	Solder	5.08 mm	Mating Flange Retention Latches	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	20 A	Female Sockets Header	1		Vertical	Thermoplastic	0.138 in	UL94 V-0	0.748 in	Copper
McGill Microwave Systems V72251500000G	Solder	5.08 mm	Retention Latches	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	20 A	Female Sockets Header	1		Vertical	Thermoplastic	0.138 in	UL94 V-0	0.748 in	Copper
McGill Microwave Systems V72271500000G	Solder	0.197 in	Retention Latches	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	10 A	Female Sockets Header	1		Vertical	Thermoplastic	0.138 in	UL94 V-0	0.748 in	Phosphor Bronze
McGill Microwave Systems V72231500000G	Solder	0.15 in		22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	8 A	Female Sockets Header	1		Vertical	Thermoplastic	0.134 in	UL94 V-0	0.571 in	Phosphor Bronze
McGill Microwave Systems V72252510000G	Solder	5.08 mm	Mating Flange Retention Latches	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	20 A	Female Sockets Header	1	90 °	Right Angle	Thermoplastic	0.138 in	UL94 V-0		Copper
McGill Microwave Systems V72212510000G	Solder	0.138 in	Mating Flange	22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	4 A	Female Sockets Header	1	90 °	Right Angle	Thermoplastic	0.134 in	UL94 V-0	0.268 in	Phosphor Bronze
McGill Microwave Systems V72211500000G	Solder	0.138 in		22	Green	Through Hole	300 V	22	-40 °C	115 °C	Tin	4 A	Female Sockets Header	1		Vertical	Thermoplastic	0.134 in	UL94 V-0	0.571 in	Phosphor Bronze
