3100-30 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONTACTOR 120VAC 3PST-NO-DM 50A FLANGE MOUNT
| Part | Contact Material | Coil Power | Coil Resistance | Operating Temperature (Min) | Operating Temperature (Max) | Must Release Voltage | Contact Rating (Current) | Must Operate Voltage | Quick Connect Size (0.250") | Termination Style | Coil Voltage | Mounting Type | Pin Count | Contact Form | Switching Voltage AC (Max) | Features | Coil Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 14 W | 45 Ohms | -40 °C | 65 °C | 20 VAC | 50 A | 93 VAC | 0.25 in | Quick Connect Screw Terminal | 120 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 7 Ohms | -40 °C | 65 °C | 6 VDC | 40 A | 18 VDC | 0.25 in | Quick Connect Screw Terminal | 24 VDC | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 320 W | 180 Ohms | -40 °C | 65 °C | 40 VDC | 50 A | 177 VAC | 0.25 in | Quick Connect Screw Terminal | 240 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | 1.3 A |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 720 Ohms | -40 °C | 65 °C | 40 VDC | 20 A | 177 VAC | 0.25 in | Quick Connect Screw Terminal | 240 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 720 Ohms | -40 °C | 65 °C | 40 VDC | 25 A | 177 VAC | 0.25 in | Quick Connect Screw Terminal | 240 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 950 Ohms | -40 °C | 65 °C | 65 VAC | 40 A | 220 VAC | 0.25 in | Quick Connect Screw Terminal | 277 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 14 W | 2.4 Ohms | -40 °C | 65 °C | 6 VDC | 60 A | 18 VDC | 0.25 in | Quick Connect Screw Terminal | 24 VDC | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 82 W | 7 Ohms | -40 °C | 65 °C | 6 VDC | 30 A | 18 VDC | 0.25 in | Quick Connect Screw Terminal | 24 VDC | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | 3.4 A |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 720 Ohms | -40 °C | 65 °C | 40 VDC | 30 A | 177 VAC | 0.25 in | Quick Connect Screw Terminal | 240 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation | |
 TE Connectivity AMP Connectors | Silver Cadmium Oxide (AgCdO) | 5 W | 720 Ohms | -40 °C | 65 °C | 40 VDC | 30 A | 177 VAC | 0.25 in | Quick Connect Screw Terminal | 240 V | Chassis Mount | 3 pins | 3 DM Form PST-NO X | 600 VAC | Class B Insulation |
