ADN4652 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

5 KV/3.75 KV RMS, 600 MBPS DUAL CHANNEL LVDS ISOLATOR

Part	Voltage - Isolation	Type	Rise / Fall Time (Typ)	Rise / Fall Time (Max)	Package Name	Operating Temperature (Max)	Operating Temperature (Min)	Number of Channels	Propagation Delay tpLH (Max)	Propagation Delay tpHL (Max)	Inputs - Side 1	Inputs - Side 2	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Isolated Power	Data Rate	Common Mode Transient Immunity (Min)	Mounting Type	Technology	Package Length	Package Width	Channel Type	Supplied Contents	Primary Attributes	Function	Utilized IC / Part	Contents	Secondary Attributes
Analog Devices Inc./Maxim Integrated ADN4652BRWZ-RL7	5000 Vrms	LVDS	0.35 ns	0.35 ns	20-SOIC	125 °C	-40 °C	2	4.5 ns	4.5 ns	1	1	2.625 V	2.375 V	No	600 Mbps	25 kV/µs	Surface Mount	Magnetic Coupling	0.295 in	7.5 mm	Unidirectional
Analog Devices Inc./Maxim Integrated EVAL-ADN4652EBZ		Interface																					Board(s)	2-Channel (Dual)	Digital Isolator	ADN4652	Board
Analog Devices Inc./Maxim Integrated ADN4652BRSZ-RL7	3750 VDC	LVDS	0.35 ns	0.35 ns	20-SSOP	125 °C	-40 °C	2	4.5 ns	4.5 ns	1	1	2.625 V	2.375 V	No	600 Mbps	25 kV/µs	Surface Mount	Magnetic Coupling	0.209 in	5.3 mm	Unidirectional
Analog Devices Inc./Maxim Integrated ADN4652BRWZ	5000 Vrms	LVDS	0.35 ns	0.35 ns	20-SOIC	125 °C	-40 °C	2	4.5 ns	4.5 ns	1	1	2.625 V	2.375 V	No	600 Mbps	25 kV/µs	Surface Mount	Magnetic Coupling	0.295 in	7.5 mm	Unidirectional
Analog Devices Inc./Maxim Integrated ADN4652BRSZ	3750 VDC	LVDS	0.35 ns	0.35 ns	20-SSOP	125 °C	-40 °C	2	4.5 ns	4.5 ns	1	1	2.625 V	2.375 V	No	600 Mbps	25 kV/µs	Surface Mount	Magnetic Coupling	0.209 in	5.3 mm	Unidirectional
Analog Devices Inc./Maxim Integrated EVAL-ADN4652EB1Z		Interface																					Board(s)	2-Channel (Dual)	Digital Isolator	ADN4652	Board	SMA Connectors
