303W3CS Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
D SUB HOUSING, RCPT, 3POS, DA-3W3C ROHS COMPLIANT: YES
| Part | Color | Note | Operating Temperature (Max) | Operating Temperature (Min) | Dielectric Material | Number of Rows | Flange Feature | Ingress Protection | Contact Type | Connector Style | Mounting Type | Number of Positions | Position Types | Finish | Shell Material | Shell Finish Thickness | Connector Layout | Part Code | Shell Size | Connector Type | Contact Material | Voltage Rating | Termination | Current Rating | Contact Finish | Material Flammability Rating | Features | Backset Spacing | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Green | Contacts Not Included | 125 °C | -55 °C | Glass Filled Polybutylene Terephthalate (PBT) | 1 | Housing Shell (Unthreaded) | IP20 | Coax Coax or Power Power | Combo D-Sub | Free Hanging (In-Line) | 3 | Coax Power | Tin Plated | Steel | 320 µin | 3W3CS 3W3K A DA | 3V3 | 2 | Receptacle for Female Contacts | |||||||||
 McGill Microwave Systems | Green | 125 °C | -55 °C | Glass Filled Polybutylene Terephthalate (PBT) | 1 | Housing Shell (Unthreaded) | Power | Combo D-Sub | Free Hanging (In-Line) | 3 | Power | Tin Plated | Steel | A DA | 3W3 | 2 | Female Sockets Receptacle | Copper Alloy | 250 V | Solder Cup | 20 A | Gold | UL94 V-0 | ||||||
McGill Microwave Systems | Female Sockets Receptacle | ||||||||||||||||||||||||||||
McGill Microwave Systems | Green | 125 °C | -55 °C | Glass Filled Polybutylene Terephthalate (PBT) | 1 | Power | Combo D-Sub | 3 | Power | Tin Plated | Steel | A DA | 3W3 | 2 | Female Sockets Receptacle | Copper Alloy | 250 V | 20 A | Gold | UL94 V-0 | Board Lock | ||||||||
 McGill Microwave Systems | Green | Contacts Not Included | 125 °C | -55 °C | Glass Filled Polybutylene Terephthalate (PBT) | 1 | Cable Side (4-40) | IP20 | Coax Coax or Power Power | Combo D-Sub | Free Hanging (In-Line) | 3 | Coax Power | Tin Plated | Steel | 320 µin | 3W3CS 3W3K A DA | 3V3 | 2 | Receptacle for Female Contacts | |||||||||
 McGill Microwave Systems | Green | 125 °C | -55 °C | Glass Filled Polybutylene Terephthalate (PBT) | 1 | Housing Shell (4-40) | Power | Combo D-Sub | Board Edge Right Angle Through Hole | 3 | Power | Tin Plated | Steel | A DA | 3W3 | 2 | Female Sockets Male Pins Receptacle | Copper Alloy | Solder | 20 A | Gold | UL94 V-0 | Board Lock Mounting Brackets | 0.459 in | 30 µin |
