AD7915 Series

Catalog

1-CHANNEL SINGLE ADC SAR 1MSPS 16-BIT SERIAL 10-PIN MSOP T/R

Part	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Package Name	Architecture	Ratio - ADC	Ratio - S/H	Operating Temperature (Max)	Operating Temperature (Min)	Package Length	Package Width	Number of Bits	Number of A/D Converters	Sampling Rate (Per Second)	Reference Type	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Configuration	Data Interface	Mounting Type	Input Type	Number of Inputs	Supplied Contents	Contents	Input Range	Utilized IC / Part	Power (Typ)	Package / Case
Analog Devices Inc./Maxim Integrated AD7915BRMZ-RL7	2.375 V	2.625 V	10-MSOP 10-TFSOP	SAR	1	1	125 °C	-40 °C	0.118 in	3 mm	16 bits	1 count	1 MHz	External	2.375 V	2.625 V	S/H-ADC	DSP SPI	Surface Mount	Differential	1
Analog Devices Inc./Maxim Integrated EVAL-AD7915SDZ											16 bits	1 count	1 MHz					DSP MICROWIRE™ QSPI™ Serial SPI™				Board(s) Power Supply	Board Power Supply	±VREF	AD7915	7 mW
Analog Devices Inc./Maxim Integrated AD7915BRMZ	2.375 V	2.625 V	10-MSOP 10-TFSOP	SAR	1	1	125 °C	-40 °C	0.118 in	3 mm	16 bits	1 count	1 MHz	External	2.375 V	2.625 V	S/H-ADC	DSP SPI	Surface Mount	Differential	1
Analog Devices Inc./Maxim Integrated AD7915BCPZ-RL7	2.375 V	2.625 V	10-LFCSP-WD	SAR	1	1	125 °C	-40 °C	3 mm	3 mm	16 bits	1 count	1 MHz	External	2.375 V	2.625 V	S/H-ADC	DSP SPI	Surface Mount	Differential	1						10-VFDFN Exposed Pad CSP
