DS Series
Manufacturer: Wakefield Thermal Solutions
Beta
⌘K
DC FANS DC SERVER FAN, 40X40X28MM, 12VDC, 35.0CFM, 2.34A, 28.08W, 67.5DBA, BALL, 4 LEADS
| Part | Voltage - Rated | Power (Watts) | Features | Air Flow | Material - Frame | Approval Agency | Width | Termination Leads Count | Termination Type | Termination | Static Pressure | Material - Blade | Noise | Fan Type | Current Rating | RPM | Bearing Type | Lifetime | Size / Dimension Length | Size / Dimension Shape | Size / Dimension Height | Operating Temperature (Max) | Operating Temperature (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Wakefield Thermal Solutions | 12 VAC | 28.08 W | PWM Control Speed Sensor (Tach) | 35 CFM | Polybutylene Terephthalate (PBT) | CE | 28 mm | 4 leads | Wire Leads | 4 Wire Leads | 5.888 in H2O | PBT Polybutylene Terephthalate | 67.5 dB | Tubeaxial | 2.34 A | 30000 RPM | Ball | 70000 Hrs | 40 mm | Square | 40 mm | 158 °F | 14 °F |
 Wakefield Thermal Solutions | 12 VAC | 40.32 W | PWM Control Speed Sensor (Tach) | 78 CFM | CE | 38 mm | 4 leads | Wire Leads | 4 Wire Leads | 4.744 in H2O | 71.5 dB | Tubeaxial | 21500 RPM | Ball | 60 mm | Square | 60 mm | 158 °F | 14 °F | ||||
Wakefield Thermal Solutions | 12 VAC | 28.08 W | PWM Control Speed Sensor (Tach) | 35 CFM | CE | 28 mm | 4 leads | Wire Leads | 4 Wire Leads | 5.888 in H2O | 67.5 dB | Tubeaxial | 30000 RPM | Ball | 40 mm | Square | 40 mm | 158 °F | 14 °F | ||||
Wakefield Thermal Solutions | 12 VAC | 40.32 W | PWM Control Speed Sensor (Tach) | 78 CFM | Polybutylene Terephthalate (PBT) | CE | 38 mm | 4 leads | Wire Leads | 4 Wire Leads | 4.744 in H2O | PBT Polybutylene Terephthalate | 71.5 dB | Tubeaxial | 3.36 A | 21500 RPM | Ball | 70000 Hrs | 60 mm | Square | 60 mm | 158 °F | 14 °F |
