ADCMP395 Series

Catalog

DUAL COMPARATOR WITH ACCURATE REFERENCE OUTPUT

Part	Mounting Type	Current - Quiescent (Max)	Package Length	Package Name	Package Width	Supply Configuration	Voltage - Supply (Single) Minimum	Voltage - Supply (Single) Maximum	Output Type	Current - Input Bias (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Propagation Delay (Max)	Voltage - Input Offset (Max)	Number of Elements	CMRR (Typ)	PSRR (Typ)	Type	Hysteresis
Analog Devices Inc./Maxim Integrated ADCMP395ARMZ-RL7	Surface Mount	51.9 µA	0.118 in	10-MSOP 10-TFSOP	3 mm	Dual Single	2.3 V	5.5 V	Open-Drain	0.03 µA	125 °C	-40 °C	9.7 µs	2.5 mV	2	74 dB	80 dB	General Purpose Standard (General Purpose)	4 mV
Analog Devices Inc./Maxim Integrated ADCMP395ARMZ	Surface Mount	51.9 µA	0.118 in	10-MSOP 10-TFSOP	3 mm	Dual Single	2.3 V	5.5 V	Open-Drain	0.03 µA	125 °C	-40 °C	9.7 µs	2.5 mV	2	74 dB	80 dB	General Purpose Standard (General Purpose)	4 mV
