NBB5-18 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE PROXIMITY SENSOR, BASIC SERIES, 5 MM, CYLINDRICAL, PNP, 10 TO 30 VDC, PRE-WIRED
| Part | Ingress Protection | Termination Style | Sensing Distance | Shielding | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Operating Temperature (Max) | Operating Temperature (Min) | Output Type | Package / Case | Material - Body | Indicator | Sensor Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | IP67 | Cable | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 4-Wire NO NPN-NC | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Cable | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 4-Wire NO NPN-NC | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Connector | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 4-Wire NO PNP-NC | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Cable | 0.197 " | Unshielded | 5 V | 60 V | 70 °C | -25 °C | 2-Wire SCR-NO | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Cable | 0.197 " | Unshielded | 20 VDC | 253 V | 70 °C | -25 °C | 2-Wire SCR-NO | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Connector | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -40 °C | 3-Wire PNP-NO | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Connector | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 3-Wire NPN-NO | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Connector | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 3-Wire PNP-NO | Cylinder Threaded - M18 | Polytetrafluoroethylene (PTFE) | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Cable | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 3-Wire PNP-NO | Cylinder Threaded - M18 | Nickel-Plated Brass | LED | Inductive |
 Pepperl+Fuchs, Inc. | IP67 | Connector | 0.197 " | Unshielded | 10 VDC | 30 VDC | 70 °C | -25 °C | 3-Wire PNP-NO | Cylinder Threaded - M18 | Polytetrafluoroethylene (PTFE) | LED | Inductive |
