901-96 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN SMA JACK STR 50 OHM SOLDER
| Part | Connector Style | Housing Color | Center Contact Material | Ingress Protection | Connector Type | Mounting Type | Cable Group | Frequency - Max | Fastening Type | Contact Termination | Shield Termination | Mounting Feature | Impedance | Number of Ports | Mating Cycles | Includes | Includes Total Count | Center Contact Plating | Operating Temperature (Min) | Operating Temperature (Max) | Dielectric Material | Voltage Rating | Body Material | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | SMA | Silver | Beryllium Copper | Weatherproof | Female Socket Jack | Panel Mount | 188 316 Double Braid M17/152-RD316 RG-179 | 12.4 GHz | Threaded | Solder | Crimp | Bulkhead Front Side Nut | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Lockwasher Nuts | 8 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 375 V | Stainless Steel | |
 McGill Microwave Systems | SMA | Gold | Beryllium Copper | Weatherproof | Female Socket Jack | Free Hanging (In-Line) | 142 223 400 RG-55 | 12.4 GHz | Threaded | Solder | Crimp | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Nut | 6 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 500 V | Stainless Steel | Gold | |
 McGill Microwave Systems | SMA | Silver | Beryllium Copper | Weatherproof | Male Pin Plug | Free Hanging (In-Line) | 188 188A 316 LMR-100 M17/119-RG174 RG-174 | 12.4 GHz | Threaded | Solder | Crimp | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Nut | 6 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 375 V | Stainless Steel | ||
 McGill Microwave Systems | SMA | Silver | Beryllium Copper | Weatherproof | Female Socket Jack | Panel Mount | 142 223 400 RG-55 | 12.4 GHz | Threaded | Solder | Crimp | Bulkhead Front Side Nut | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Lockwasher Nuts | 8 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 500 V | Stainless Steel | |
 McGill Microwave Systems | SMA | Silver | Beryllium Copper | Weatherproof | Male Pin Plug | Free Hanging (In-Line) | 142 223 400 RG-55 | 12.4 GHz | Threaded | Solder | Crimp | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Nut | 6 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 500 V | Stainless Steel | ||
 McGill Microwave Systems | SMA | Gold | Beryllium Copper | Weatherproof | Male Pin Plug | Free Hanging (In-Line) | 188 188A 316 LMR-100 M17/119-RG174 RG-174 | 12.4 GHz | Threaded | Solder | Crimp | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Nut | 6 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 375 V | Stainless Steel | Gold | |
 McGill Microwave Systems | SMA | Silver | Beryllium Copper | Weatherproof | Female Socket Jack | Panel Mount | 188 188A 316 LMR-100 M17/119-RG174 RG-174 | 12.4 GHz | Threaded | Solder | Crimp | Bulkhead Front Side Nut | 50 Ohm | 1 | 500 cycles | Connector Contact Ferrule Heat Shrink Insulator Lockwasher Nuts | 8 pcs | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | 375 V | Stainless Steel |
