NBB4-12 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE SEN 4MM NO
| Part | Indicator | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Supply (Range 2 Maximum) | Voltage - Supply (Range 1 Minimum) | Voltage - Supply (Range 1 Maximum) | Voltage - Supply (Range 2 Minimum) | Output Type | Termination Style | Ingress Protection | Sensing Distance | Package / Case | Sensor Type | Material - Body | Shielding | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 300 VDC | 20 VAC | 250 VAC | 20 VDC | 2-Wire SCR-NO | Connector | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | ||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -40 °C | 3-Wire PNP-NO | Connector | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 4-Wire NO PNP-NC | Connector | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 85 °C | -40 °C | 3-Wire PNP-NO | Connector | IP68 IP69K | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 5 V | 60 V | ||||
Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 3-Wire NPN-NO | Connector | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 3-Wire PNP-NO | Cable | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 4-Wire NO NPN-NC | Connector | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 300 VDC | 20 VAC | 250 VAC | 20 VDC | 2-Wire SCR-NO | Cable | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | ||
 Pepperl+Fuchs, Inc. | LED | 70 °C | -25 °C | 3-Wire PNP-NO | Cable | IP67 | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 10 VDC | 30 VDC | ||||
 Pepperl+Fuchs, Inc. | LED | 85 °C | -40 °C | 3-Wire PNP-NC | Cable | IP68 IP69K | 0.157 " | Cylinder Threaded - M12 | Inductive | Nickel-Plated Brass | Unshielded | 5 V | 60 V |
