FLS014N Series

Catalog

7 POSITION SQUARE FLANGE RECEPTA

Part	Housing Color	Type	Fastening Type	Shell Size - Insert Width	Shell Size - Insert Length	Contact Shape	Shielding	Note	Number of Positions	Material Flammability Rating	Insert Material	Ingress Protection IP Rating	Ingress Protection Description	Mounting Feature	Contact Type	Contact Size	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Connector Type	Primary Material	Orientation	Shell Material	Features	Shell Size - Insert (Maximum)	Shell Size - Insert (Minimum)
McGill Microwave Systems FLS014N7P03	Black	For Male Pins	Bayonet Lock	7 mm	14 mm	Circular	Unshielded	Contacts Not Included	7	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	16 S	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N3P03	Black	For Male Pins	Bayonet Lock	3 mm	14 mm	Circular	Unshielded	Contacts Not Included	3	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	8	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N19PHEC03	Black	For Male Pins	Bayonet Lock			Circular	Unshielded	Contacts Not Included	19	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	20	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic	Cap (Cover)	19	14 S
McGill Microwave Systems FLS014N4S03	Black	For Female Sockets	Bayonet Lock	4 mm	14 mm	Circular	Unshielded	Contacts Not Included	4	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	12	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N3S03	Black	For Female Sockets	Bayonet Lock	3 mm	14 mm	Circular	Unshielded	Contacts Not Included	3	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	8	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N3S03-PM	Black	For Female Sockets	Bayonet Lock	3 mm	14 mm	Circular	Unshielded	Contacts Not Included	3	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	8	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N4S03-PM	Black	For Female Sockets	Bayonet Lock	4 mm	14 mm	Circular	Unshielded	Contacts Not Included	4	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	12	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N12S03-PM	Black	For Female Sockets	Bayonet Lock	12 mm	14 mm	Circular	Unshielded	Contacts Not Included	12	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	16 S	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
McGill Microwave Systems FLS014N19SHEC03	Black	For Female Sockets	Bayonet Lock			Circular	Unshielded	Contacts Not Included	19	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	20	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic	Cap (Cover)	19	14 S
McGill Microwave Systems FLS014N12S03	Black	For Female Sockets	Bayonet Lock	12 mm	14 mm	Circular	Unshielded	Contacts Not Included	12	UL94 V-0	Thermoplastic	IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Flange	Crimp	16 S	125 °C	-40 °C	Panel Mount	Receptacle Housing	Plastic	N (Normal)	Thermoplastic
