AD9257 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

ANALOG TO DIGITAL CONVERTER, 14 BIT, 40 MSPS, DIFFERENTIAL, SERIAL, SPI, SINGLE, 1.7 V

Part	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Package Length	Package Name	Package Width	Data Interface	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Number of Bits	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Sampling Rate (Per Second)	Number of A/D Converters	Input Type	Configuration	Architecture	Number of Inputs	Mounting Type	Reference Type	Ratio - ADC	Ratio - S/H	Features
Analog Devices Inc./Maxim Integrated AD9257BCPZ-40	1.7 V	1.9 V	9 mm	64-LFCSP-VQ	9 mm	LVDS - Serial	1.9 V	1.7 V	14 bits	64-VFQFN Exposed Pad CSP	-40 °C	85 °C	40 MHz	8 count	Differential	S/H-ADC	Pipelined	8	Surface Mount	Internal	1	1	Simultaneous Sampling
Analog Devices Inc./Maxim Integrated AD9257BCPZ-65	1.7 V	1.9 V	9 mm	64-LFCSP-VQ	9 mm	LVDS - Serial	1.9 V	1.7 V	14 bits	64-VFQFN Exposed Pad CSP	-40 °C	85 °C	65 MHz	8 count	Differential	S/H-ADC	Pipelined	8	Surface Mount	Internal	1	1	Simultaneous Sampling
Analog Devices Inc./Maxim Integrated AD9257TCPZ-65-EP	1.7 V	1.9 V	9 mm	64-LFCSP	9 mm	LVDS - Serial	1.9 V	1.7 V	14 bits	64-WFQFN Exposed Pad CSP	-55 °C	125 °C	65 MHz	8 count	Differential	S/H-ADC	Pipelined	8	Surface Mount	Internal	1	1	Simultaneous Sampling
Analog Devices Inc./Maxim Integrated AD9257BCPZRL7-65	1.7 V	1.9 V	9 mm	64-LFCSP-VQ	9 mm	LVDS - Serial	1.9 V	1.7 V	14 bits	64-VFQFN Exposed Pad CSP	-40 °C	85 °C	65 MHz	8 count	Differential	S/H-ADC	Pipelined	8	Surface Mount	Internal	1	1	Simultaneous Sampling
Analog Devices Inc./Maxim Integrated AD9257BCPZRL7-40	1.7 V	1.9 V	9 mm	64-LFCSP-VQ	9 mm	LVDS - Serial	1.9 V	1.7 V	14 bits	64-VFQFN Exposed Pad CSP	-40 °C	85 °C	40 MHz	8 count	Differential	S/H-ADC	Pipelined	8	Surface Mount	Internal	1	1	Simultaneous Sampling
