Description
General part information
SFH 4775S-EB2FB1-11
Infrared (IR) Emitter 950nm 2.9V 1.5A 420mW/sr 120° 1108 (2720 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | SFH 4775S-EB2FB1-11 |
|---|---|
| Current - DC Forward (If) (Max) | 1.5 A |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation | Top View |
| Package / Case | 1108 (2720 Metric) |
| Radiant Intensity (Ie) Min | 420 mW/sr |
| Type | Infrared (IR) |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 2.9 V |
| Wavelength | 950 nm |
