5452420
ActivePhoenix Contact
TERM BLOCK HDR 10POS VERT 5.08MM
5452420
ActivePhoenix Contact
TERM BLOCK HDR 10POS VERT 5.08MM
Description
General part information
5452420
10 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.200" (5.08mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5452420 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.154 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Header Orientation | Vertical |
| Insulation Height | 0.472 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 10 |
| Pitch | 5.08 mm |
| Positions Per Level | 10 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
