UDA1352TS/N3,112
ObsoleteNXP USA Inc.
IC DAC/AUDIO 20BIT 48K 28SSOP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UDA1352TS/N3,112
ObsoleteNXP USA Inc.
IC DAC/AUDIO 20BIT 48K 28SSOP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | UDA1352TS/N3,112 | UDA135 Series |
|---|---|---|
| Data Interface | I2C | I2C, PCM, Serial |
| Mounting Type | Surface Mount | Surface Mount |
| Number of ADCs / DACs | - | 2 |
| Number of ADCs / DACs | - | 2 |
| Number of Channels [custom] | 3 | 2 - 3 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 28-SSOP | 28-SSOP, 44-QFP |
| Package / Case [custom] | 0.209 in | 0.209 in |
| Package / Case [custom] | 5.3 mm | 5.3 mm |
| Resolution (Bits) | 20 b | 20 - 24 b |
| S/N Ratio, ADCs / DACs (db) Typ | - | 98 db |
| S/N Ratio, ADCs / DACs (db) Typ | - | 97 db |
| Sampling Rate (Per Second) | 48 k | 48 k |
| Sampling Rate (Per Second) | - | 100k |
| Sigma Delta | - | False |
| Supplier Device Package | 28-SSOP | 28-SSOP, 44-PQFP (10x10) |
| Type | Audio, DAC | Audio, DAC, Stereo Audio |
| Voltage - Supply [Max] | 3.6 V | 3.6 V |
| Voltage - Supply [Min] | 2.7 V | 2.7 V |
| Voltage - Supply, Analog | - | 2.7 V |
| Voltage - Supply, Analog | - | 5.5 V |
| Voltage - Supply, Digital | - | 5.5 V |
| Voltage - Supply, Digital | - | 2.7 V |
| Voltage Supply Source | Analog and Digital | Analog and Digital |
UDA135 Series
IC DAC/AUDIO 20BIT 48K 28SSOP
| Part | Supplier Device Package | Voltage Supply Source | Data Interface | Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Number of Channels [custom] | Sampling Rate (Per Second) | Mounting Type | Resolution (Bits) | Package / Case [custom] | Package / Case | Package / Case [custom] | Sampling Rate (Per Second) | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog [Max] | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Sigma Delta | S/N Ratio, ADCs / DACs (db) Typ [custom] | S/N Ratio, ADCs / DACs (db) Typ [custom] | Number of ADCs / DACs [custom] | Number of ADCs / DACs [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
NXP USA Inc. UDA1352TS/N3,118 | 28-SSOP | Analog and Digital | I2C | Audio, DAC | 85 °C | -40 °C | 2.7 V | 3.6 V | 3 | 48 k | Surface Mount | 20 b | 0.209 in | 28-SSOP | 5.3 mm | ||||||||||
NXP USA Inc. UDA1351H/N1,557 | 44-PQFP (10x10) | Analog and Digital | PCM | Audio, DAC | 85 °C | -40 °C | 2.7 V | 3.6 V | 2 | Surface Mount | 24 b | 44-QFP | 100k | ||||||||||||
NXP USA Inc. UDA1351TS/N1,512 | 28-SSOP | Analog and Digital | PCM | Audio, DAC | 85 °C | -40 °C | 2.7 V | 3.6 V | 2 | Surface Mount | 20 b | 0.209 in | 28-SSOP | 5.3 mm | 100k | ||||||||||
NXP USA Inc. UDA1351TS/N1,518 | 28-SSOP | Analog and Digital | PCM | Audio, DAC | 85 °C | -40 °C | 2.7 V | 3.6 V | 2 | Surface Mount | 20 b | 0.209 in | 28-SSOP | 5.3 mm | 100k | ||||||||||
NXP USA Inc. UDA1355H/N2,518 | 44-PQFP (10x10) | I2C, Serial | Stereo Audio | 85 °C | -40 °C | Surface Mount | 24 b | 44-QFP | 2.7 V | 5.5 V | 5.5 V | 2.7 V | 98 db | 97 db | 2 | 2 | |||||||||
NXP USA Inc. UDA1355H/N2,557 | 44-PQFP (10x10) | I2C, Serial | Stereo Audio | 85 °C | -40 °C | Surface Mount | 24 b | 44-QFP | 2.7 V | 5.5 V | 5.5 V | 2.7 V | 98 db | 97 db | 2 | 2 | |||||||||
NXP USA Inc. UDA1352TS/N3,112 | 28-SSOP | Analog and Digital | I2C | Audio, DAC | 85 °C | -40 °C | 2.7 V | 3.6 V | 3 | 48 k | Surface Mount | 20 b | 0.209 in | 28-SSOP | 5.3 mm |
