172-11-31-221

Active

Advanced Photonix

SENSOR PHOTODIODE 660NM TO5

Search across all available documentation for this part.

Active

Advanced Photonix

SENSOR PHOTODIODE 660NM TO5

Technical Specifications

Parameters and characteristics for this part

SENSOR PHOTODIODE 660NM TO5

Part	Active Area	Voltage - DC Reverse (Vr) (Max) [Max]	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Spectral Range [Min]	Spectral Range [Max]	Responsivity @ nm	Current - Dark (Typ)	Response Time	Diode Type	Color - Enhanced	Viewing Angle	Wavelength
Advanced Photonix 172-11-31-221	15.04 mm²	75 V	Through Hole	125 °C	-40 °C	350 nm	1100 nm	0.55 A/W	35 nA	8 ns	PIN	Red	79 °	660 nm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 169.90

General part information

Photodiode 660nm 8ns 79°

Technical documentation and resources
