XPEEPR-L1-0000-00C01-SB01

New Energy

LED MOD XLAMP RED STARBOARD

Search across all available documentation for this part.

New Energy

LED MOD XLAMP RED STARBOARD

Technical Specifications

Parameters and characteristics for this part

Specification	XPEEPR-L1-0000-00C01-SB01

Color	Red
Configuration	Starboard
Current - Max [Max]	1 A
Current - Test	350 mA
Height [z]	2.04 mm
Lens Type	Domed
Luminous Flux @ Current/Temperature	463 mW
Luminous Flux @ Current/Temperature [Max]	500 mW
Luminous Flux @ Current/Temperature [Min]	425 mW
Size / Dimension [diameter]	19.89 mm
Type	LED Module
Viewing Angle	130 °
Voltage - Forward (Vf) (Typ)	2.1 V
Wavelength	660 nm

LED MOD XLAMP RED STARBOARD

Part	Voltage - Forward (Vf) (Typ)	Height [z]	Viewing Angle	Configuration	Wavelength	Size / Dimension [diameter]	Current - Test	Lens Type	Color	Type	Luminous Flux @ Current/Temperature [Min]	Luminous Flux @ Current/Temperature [Max]	Luminous Flux @ Current/Temperature	Current - Max [Max]
New Energy XPEEPR-L1-0000-00C01-SB01	2.1 V	2.04 mm	130 °	Starboard	660 nm	19.89 mm	350 mA	Domed	Red	LED Module	425 mW	500 mW	463 mW	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Lighting COBs Engines Modules LED Module XLamp® XP-E Horticulture Red Starboard
