Description
General part information
A79615-001
10 Position Cable Assembly Rectangular Plug and Socket to Individual Wire Leads 1.50' (457.20mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | A79615-001 |
|---|---|
| Cable Termination | Crimp |
| Color | Multiple, Individual |
| Connector Type | Plug, Socket to Individual Wire Leads |
| Contact Finish | Gold |
| Contact Finish Thickness | 50 µin |
| Features | Polarizing Key |
| Length | 1.5 ft |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Pitch - Connector | 0.025 in |
| Shielding | Unshielded |
